2N4401TA Electronic IC Chips NPN General Pupose Amplifier

Product Categories

Anterwell Technology Ltd.

Contact Now

Name: 2N4401TA Electronic IC Chips NPN General Pupose Amplifier
Brand: Anterwell
Price: 1 USD

Brand Name : Anterwell

Model Number : 2N4401TA

Certification : new & original

Place of Origin : original factory

MOQ : 20pcs

Price : Negotiate

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 8600pcs

Delivery Time : 1 day

Packaging Details : Please contact me for details

Collector-Emitter Voltage : 40 V

Collector-Base Voltage : 60 V

Emitter-Base Voltage : 6.0 V

Collector Current - Continuous : 600 mA

Operating Junction Temperature : -55 to +150 °C

Storage Temperature : -55 to +150 °C

Contact Now

NPN General Pupose Amplifier

This device is designed for use as a medium power amplifier and switch requiring collector currents up to 500 mA.

Absolute Maximum Ratings* TA = 25°C unless otherwise noted

Symbol	Parameter	Value	Units
V_CEO	Collector-Emitter Voltage	40	V
V_CBO	Collector-Base Voltage	60	V
V_EBO	Emitter-Base Voltage	6.0	V
I_C	Collector Current - Continuous	600	mA
T_J, T_stg	Operating and Storage Junction Temperature Range	-55 to +150	°C

*These ratings are limiting values above which the serviceability of any semiconductor device may be impaired.

NOTES:

1) These ratings are based on a maximum junction temperature of 150 degrees C.

2) These are steady state limits. The factory should be consulted on applications involving pulsed or low duty cycle operations.

2N4401 MMBT4401

2N4401TA Electronic IC Chips NPN General Pupose Amplifier

Test Circuits

2N4401TA Electronic IC Chips NPN General Pupose Amplifier

FIGURE 1: Saturated Turn-On Switching Timer

2N4401TA Electronic IC Chips NPN General Pupose Amplifier

FIGURE 2: Saturated Turn-Off Switching Time
